Jib Crane Models
Jib cranes are made up of a trolley hoist on a horizontal load-bearing boom. This boom is connected to a pivoting vertical member and up to 20 feet long. Jib cranes can transport loads between any areas within the boom's arc of rotation. Light duty models are utilized inside factories and warehouses for loads weighing as much as 5 tons. The web site BestJibCranes.com features the major jib crane types as being either wall-mounted, mast mounted or free-standing.
Free Standing
The free-standing jib crane models do not need any support from the building structure and could stand by themselves. The horizontal boom in this particular case is attached to a pivoting vertical column which is solidly anchored to the floor of the building. This type of jib crane could rotate a full 360 degrees and requires a foundation made of either concrete or steel.
Mast-Type
The mast-type jib cranes feature a vertical column that is supported by pivot points at the top and the bottom which are connected to the building floor and the overhead steel structure. These jib-cranes provide 360 degrees of rotation with the benefit of not requiring the massive foundation needed for free-standing units.
Wall Mounted
The wall-mounted jib cranes provide a horizontal boom that is connected to the building wall rather than the normal vertical column. These equipments provide up to 200 degrees of rotation and are great in places where the full 360 degree rotation is not needed.
Depending on how the boom is supported, there are two model varieties. One type uses a tie rod from above the boom which is attached to the wall. The other kind supports the boom from below by using a cantilever brace which is attached to the wall also.
